Harmony Solid State Relays Solid state slim relay 2A, zero voltage switching, input 15...30V DC, output 24...280V AC

Home ProductsIndustrialHarmonySolid state slim relay

Harmony Solid State Relays Solid state slim relay 2A, zero voltage switching, input 15...30V DC, output 24...280V AC

Item Number: SSL1A12BD

Where To Buy

Datasheet

PDF datasheet

Download

Product Dimensions

Width icon

Width5 mm

Height icon

Height28 mm

Depth icon

Depth15 mm

See full specifications

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

Harmony Solid State Relays

Product or component type

plug-in relay

Physical

Insulation resistance

> 100 MOhm at 500 V DC

Mounting support

socket

[in] rated current

2 A

Width

5 mm

Height

28 mm

Depth

15 mm

Net weight

0.0041 kg

Device presentation

complete product

Standards

  • IEC/EN 60947-4-3
  • IEC/EN 62314
  • UL 508
  • C22.2 No. 14

Product certifications

  • cURus
  • CSA
  • EAC
  • CE
  • UKCA

Marking

CE

Ip degree of protection

IP00

Ambient air temperature for operation

-20...80 °C

Ambient air temperature for storage

-20...85 °C

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Pro-active compliance (Product out of EU RoHS legal scope)

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

X

Environmental disclosure

ENVPEP1307068EN

Circularity profile

NA

California proposition 65

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Others

Package 1 bare product quantity

1

Package 2 bare product quantity

12

Package 3 bare product quantity

1080

Device short name

SSL

Network number of phases

1 phase

[uc] control circuit voltage

15...30 V

Output switching mode

zero voltage switching

Short-circuit current

5000 A

Associated fuse rating

2.5 A at 250 V coordination type 1

[ui] rated insulation voltage

280 V

Electromagnetic compatibility

  • electrostatic discharge - test level: 4 kV criteria B (contact discharge) conforming to IEC 61000-4-2
  • electrostatic discharge - test level: 8 kV criteria B (air discharge) conforming to IEC 61000-4-2
  • conducted RF disturbances - test level: 10 V criteria A (0.15...80 MHz) conforming to IEC 61000-4-6
  • electrical fast transient/burst immunity test - test level: 2 kV criteria B (5 kHz) conforming to IEC 61000-4-4
  • electrical fast transient/burst immunity test - test level: 1 kV criteria B (5 kHz) conforming to IEC 61000-4-4
  • surge immunity test - test level: 1 kV criteria B (line to line) conforming to IEC 61000-4-5
  • surge immunity test - test level: 2 kV criteria B (line to earth) conforming to IEC 61000-4-5
  • surge immunity test - test level: 1 kV criteria B (line to earth) conforming to IEC 61000-4-5
  • radiated emission - test level: 30...1000 Mhz conforming to IEC 60947-1
  • conducted emission - test level: 0.15...30 Mhz conforming to IEC 60947-1

[uimp] rated impulse withstand voltage

  • 4.0 kV for input to case conforming to IEC 62314
  • 4.0 kV for input/output circuit conforming to UL 508
  • 4.0 kV output to case
  • 4.0 kV for input/output circuit conforming to IEC 62314
  • 4.0 kV output to case conforming to IEC 62314
  • 4.0 kV for input to case conforming to UL 508
  • 4.0 kV output to case conforming to UL 508

Output voltage

24...280 V AC

[uc] control circuit voltage

15...30 V DC

Capacitance unbalance

2.5 pF input/output

Minimum switching voltage

15 V DC turn-on

Maximum switching voltage

10 V DC turn-off

Input current

10 mA

Input impedance

2500 Ohm

Solid state output type

  • zero voltage switching
  • SCR output

Load current

0.07...2 A

Absolute maximum voltage

600 V

Surge current

  • 84 A for 16.6 ms
  • 80 A for 20 ms

Maximum voltage drop

<1.5 V on-state

Maximum i²t for fusing

  • 33 A².s for 10 ms at 50 Hz
  • 29 A².s for 8.3 ms at 60 Hz

Maximum leakage current

4 mA off-state

Dv/dt

500 V/µs off-state at maximum voltage

Response time

  • 0.5 cycle (turn-on)
  • 0.5 cycle (turn-off)

Overvoltage category

III

Flame retardance

V0 conforming to UL 94

Dielectric strength

2500 V for input/output

Pollution degree

2

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

0.700 cm

Package 1 width

2.500 cm

Package 1 length

37.000 cm

Package 1 weight

5.000 g

Unit type of package 2

BB1

Number of units in package 2

12

Package 2 height

0.700 cm

Package 2 width

2.500 cm

Package 2 length

37.000 cm

Package 2 weight

61.000 g

Unit type of package 3

S01

Number of units in package 3

1080

Package 3 height

15.000 cm

Package 3 width

15.000 cm

Package 3 length

40.000 cm

Package 3 weight

5.684 kg

Packaging made with recycled cardboard

Yes

Packaging without single use plastic

No

Green premium status for reporting

Green Premium product

Take-back

No

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A

Global warming ; total life cycle​

10 kg CO2 eq.

Carbon footprint (kg.eq.co2 per cr, total life cycle)

10.1501050563

Minimum percentage of recycled plastic content

0
