Clipsal Saturn Zen Grid and Cover 1 Gang, Less Mechanism

Zen White | Clipsal Saturn Zen Grid and Cover 1 Gang, Less Mechanism

Clipsal Saturn Zen Grid and Cover 1 Gang, Less Mechanism

Item Number: Z4031VH-ZW

Retail
$48.66
RRP (Inc. GST)

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-
Saturn Zen Fascia Removal Process

Features

  • Fingerprint-resistant matte finish
  • Simple to fit and swap-out fascia
  • Can be applied vertically or horizontally

Specifications

Design

Product brand

Clipsal

Sustainable offer status

Green Premium product

Physical

REACh Regulation

Free of Substances of Very High Concern above the threshold

REACh free of SVHC

Yes

EU RoHS Directive

Compliant

Toxic heavy metal free

Yes

Mercury free

Yes

RoHS exemption information

Yes

China RoHS Regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Environmental Disclosure

ENVPEP111024EN

Circularity Profile

ENVEOLI110713EN

Others

Package 1 Weight

103 g

Package 1 Height

20 mm

Package 1 width

76 mm

Package 1 Length

122 mm
Show all specifications

Frequently Asked Questions

hide show

What is the part number of a 3 position mechanism in the Saturn Zen range?

39M is a 30 Series, 3 Position 10A Mechanisms, Marked - LO - Off - HI. 30 series mechanism will fit on Saturn Zen  Z403*VH ( Example Z4031VH) Grid and Cover Assembly, accepts 30 Series Mechanisms (Including DATA/COMMS, 30PB and 30PBL)
* - 1, 2, 3, 4, 6
For further information, please visit:
https://www.clipsal.com/Trade/Products/ProductDetail?catno=39M

https://www.clipsal.com/Trade/Products/ProductDetail?catno=Z4031VH



Is there a 35A Mech for Saturn Zen Series

No there is no saturn mech available. There is either the Z4061/45 or Z4061D32 cooker switch plate or the 30M35 in a Z4031VH Plate

Is there an Auto-Off-Manual three position switch available for Saturn Zen?

You will need to use one of the Saturn Zen Communication Plates and a 30 series Auto-Off-Man mechanism.
The part numbers are:

Z4031VH

39MAOM

Z4031VH - Grid And Plate Assembly 1 Gang Saturn ZEN39MAOM - Switch, 1 Pole, 250VAC, 10A, Auto/Off/Man

What parts do you use for TV, Data, Phone etc for Saturn Zen?


To use TV, Data and phone mechanisms in the Saturn ZEN range you will first need to select the Communication Grid plate.
For example:
Size of PlatePart Number
Saturn ZEN - 1 Gang Grid PlateZ4031VH-**
Saturn ZEN - 2 Gang Grid PlateZ4032VH-**
Saturn ZEN - 3 Gang Grid PlateZ4033VH-**
Saturn ZEN - 4 Gang Grid PlateZ4034VH-**
Saturn ZEN - 6 Gang Grid PlateZ4036VH-**
**Colour code, e.g. ZB=ZEN Black, ZW=ZEN White

Once you have selected your communiation plate, the standard 30 Series mechanisms will suit.

For further information please visit https://www.clipsal.com/products/saturn-zen

Clipsal Saturn Zen group shot

Range

Pure Simplicity, Unique Features

Clipsal Saturn Zen is a range of modern light switches and power points presenting a clean refined appearance.

The range includes push button wall switches, power outlets, data outlets, USB chargers, fan controllers, dimmers, and cooker switches.

Options include interchangeable pictogram button icons and a Smart Shelf for charging electronic devices; designed to make your life easier.

Saturn Zen combines form, function and affordability to create a complete switch solution for the home.
