Weathershield Switch, 1-Gang, 4 Pole, 40A, 500VAC, IP66 1-Gang, 4 Pole, 40A, 500VAC, IP66

Back to WHB Series Isolators Home Surface Mount WHB Series Isolators

Resistant Grey | Weathershield Switch, 1-Gang, 4 Pole, 40A, 500VAC, IP66 1-Gang, 4 Pole, 40A, 500VAC, IP66

Weathershield Switch, 1-Gang, 4 Pole, 40A, 500VAC, IP66 1-Gang, 4 Pole, 40A, 500VAC, IP66

Item Number: WHB440-RG

The WHB Series of Weathershield lever switches are a robust range of switches suitable for many external application. There are various configurations within the range such as, single, double, triple and four pole switches with various ranges from 20 to 55 Amps. The base mounted mechanism on WHB provides for easier termination and more wiring room. The switch has an IP66 rating to prevent dust and water ingress.

Where To Buy

Datasheet

Download

Barcode

Qty UoM EAN Colour
-
-
-
See all

Specifications

Design

Range of product

Weathershield

Product or component type

switch

Product brand

Clipsal

Sustainable offer status

Green Premium product

Physical

Fixing mode

by screws

Device mounting

surface

Standards

  • AS 60529
  • AS/NZS 60947-3
  • IEC 60669-1
  • AS/NZS 3947-3:approval number S/1

REACh Regulation

Free of Substances of Very High Concern above the threshold

REACh free of SVHC

Yes

EU RoHS Directive

Compliant

Toxic heavy metal free

Yes

Mercury free

Yes

China RoHS Regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

RoHS exemption information

Yes

Environmental Disclosure

ENVPEP130201EN

Others

Package 1 Bare Product Quantity

1

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

8.7 cm

Package 1 Width

9.7 cm

Package 1 Length

17.0 cm

Package 1 Weight

553.0 g
Show all specifications
