EVlink Pro AC Cable holder Metal, installed on side of metal kit enclosure

Item Number: EVA1FWHS12

Cable Holder for Evlink Pro AC Metal

This EVlink Pro AC Metal cable accessory is a cable holder. It allows to leave the cable connected on the EVlink Pro AC Metal enclosure. The holder is located on the side of the charging station. The dimensions are (W) 160mm x (H) 145mm x (D) 101.5mm. Its product weight is 1.15kg. The color is light grey (RAL 9022).

Datasheet

Product Dimensions

Width160 mm

Height145 mm

Depth101.5 mm

See full specifications

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3606482185494	-

Specifications

Design

Range

EVlink

Product or component type

cable holder

Sustainable offer status

Green Premium product

Physical

Range compatibility

EVlink (EVlink Pro AC Metal)

Mounting support

enclosure

Height

145 mm

Width

160 mm

Depth

101.5 mm

Net weight

1.15 kg

REACh Regulation

Free of Substances of Very High Concern above the threshold

REACh free of SVHC

Yes

EU RoHS Directive

Compliant

Mercury free

Yes

RoHS exemption information

Yes

China RoHS Regulation

Product out of China RoHS scope. Substance declaration for your information

Environmental Disclosure

ENVPEP2202024

Circularity Profile

ENVEOLI2202024

Others

Package 1 Bare Product Quantity

1

Accessory / separate part category

cabling accessory

Mounting location

side

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

19.8 cm

Package 1 Width

20 cm

Package 1 Length

30 cm

Package 1 Weight

1.452 kg

Unit Type of Package 2

P12

Number of Units in Package 2

32

Package 2 Height

54 cm

Package 2 Width

80 cm

Package 2 Length

120 cm

Package 2 Weight

60 kg

Show all specifications
