Clipsal - Max 4 Link bar 90 A 6 hole length 72 mm

Clipsal - Max 4 Link bar 90 A 6 hole length 72 mm

Item Number: BP90A6

Where To Buy

Datasheet

Download

Barcode

Qty UoM EAN Colour
-
-
-
See all

Specifications

Design

Product brand

Clipsal

Range of product

  • Blue Point
  • Series BP90A

Product or component type

link bar

Physical

[In] rated current

90 A

Connector type

screw terminals

REACh Regulation

Reference contains Substances of Very High Concern above the threshold

EU RoHS Directive

Compliant

Mercury free

Yes

RoHS exemption information

Yes

China RoHS Regulation

Product out of China RoHS scope. Substance declaration for your information

Others

Package 1 Bare Product Quantity

1

Cable cross section

16 mm²

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

1.8 cm

Package 1 Width

1.7 cm

Package 1 Length

9.2 cm

Package 1 Weight

12 g

Unit Type of Package 2

BB1

Number of Units in Package 2

5

Package 2 Height

3.9 cm

Package 2 Width

5.5 cm

Package 2 Length

11.5 cm

Package 2 Weight

0.256 kg

Unit Type of Package 3

CAR

Number of Units in Package 3

60

Package 3 Height

25 cm

Package 3 Width

21.4 cm

Package 3 Length

33.8 cm

Package 3 Weight

720 g
Show all specifications
