UPS Network Management Card

UPS Network Management Card

UPS Network Management Card

Item Number: AP9618

Retail
N/A
RRP (Inc. GST)

Product Dimensions

Width icon

Width12.1 cm

Height icon

Height3.8 cm

Depth icon

Depth10.8 cm

See full specifications

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Warranty

2 years repair or replace

Physical

Provided equipment

  • CD with software
  • temperature sensor
  • user manual
    • Depth

      10.8 cm

      Height

      3.8 cm

      Net weight

      0.14 kg

      Mounting mode

      not rack-mountable

      Width

      12.1 cm

      Standards

    • EN 55022 class A
    • FCC part 15 class A
      • Product certifications

      • BSMI
      • C-Tick
      • CE
      • VCCI
        • Ambient air temperature for operation

          0-45 °C

          Relative humidity

          0-95 %

          Ambient air temperature for storage

          -15-65 °C

          Communication network type

          RJ45 10/100 Base-T

          Communication port protocol

        • HTTP
        • HTTPS
        • SMTP
        • SNMP
        • SSL
        • TCP/IP
        • Telnet
        • WAP
          • Others

            Additional specification

            UPS Network Management Card

            Power supply type

            self powered via SmartSlot

            Number of rack unit

            0U

            Operating altitude

            0...10000 ft

            Storage altitude

            0-50000 ft

            Storage Relative Humidity

            0-95 %
            Show all specifications

            Frequently Asked Questions

            hide show

            Where can I get support for APC and MGE Products?

            For support on APC and MGE products please visit:  https://www.apc.com/support/

            AC Power
            Additional Management Cards and Options
            Air Cooled Chillers
            Air Distribution Accessories
            Airflow Management
            AIS 3000
            AIS 5000
            AIS Accessories
            AIS Battery Systems
            APC CS
            APC Enterprise Manager
            APC ES
            APC RS
            Application Shutdown Utilities
            Assessment Services
            Auto and Air Inverters
            AV Accessories
            AV Power Conditioners & Battery Backups
            AV Power Filters
            AV Pro Interconnects
            AV Surge Protectors
            Backpacks and Messenger Bags
            Back-UPS
            Back-UPS Accessories
            Back-UPS BI
            Back-UPS CS
            Back-UPS ES
            Back-UPS HI
            Back-UPS HT
            Back-UPS LS
            Back-UPS Office
            Back-UPS Pro
            Back-UPS RS
            Back-UPS XS
            Basic Rack PDU
            Battery Management
            Battery Replacement Services
            Biometric Security
            Bulk Cable
            Cabinet Power Distribution
            Cable Management
            Charge-UPS EX
            Commercial/Industrial Surge Suppression
            Condensers
            Configurable Power Accessories
            Configurable Power Distribution
            Console Port Servers
            CyberFort
            Data Center Facility Cooling - Andover Continuum or TAC Vista
            Data Center Facility Power - PowerLogic ION Enterprise
            Data Center Software Integration Kits
            Data Center University
            Data Distribution Cable
            DC Battery
            DC Components
            DC Distribution Components
            DC600
            Desktop KVM
            Desktop Notebook Stands
            EcoBreeze Air Economizers
            Environmental Management System
            Environmental Monitoring Unit
            Ethernet Switches
            Extended Warranties
            Fiber Optics
            Firmware Upgrades
            FLM Series
            Fluid Coolers
            FRP/Ferroresonant Power Supply
            Game Console Surge Protection
            Gender Changers
            Global Deployment
            Hardwire Surge Suppression Accessories
            High-Density Cooling Enclosures
            IDE Cables
            IEEE1394
            Industrial
            InfraStruxure for Large Data Centers
            InfraStruxure for Medium Data Centers
            InfraStruxure for Server Rooms
            InfraStruxure for Small Data Centers
            InfraStruxure for Wiring Closets
            InfraStruxure Manager
            InfraStruxure Type A
            InRoom Direct Expansion
            InRow Chilled Water
            InRow Direct Expansion
            InRow Pumped Refrigerant
            Installation Services
            Interface Cables
            International Plug Adapters
            Keyboard
            KVM Switches
            Laptop Power Adapters
            Line-R
            Magnum VS
            Magnum XS
            Magnum XS Rectifier
            Maintenance Bypass Panels
            Management Platform Integration
            Matrix Battery Systems
            Matrix-UPS
            Matrix-UPS Accessories
            Metered Rack PDU
            Metered-by-Outlet Rack PDU
            MGE Accessories
            MGE Alpes
            MGE Battery Systems
            MGE Comet
            MGE EPS
            MGE EPS 6000
            MGE EPS 7000
            MGE EPS 8000
            MGE Galaxy
            MGE Galaxy 300
            MGE Galaxy 3000
            MGE Galaxy 3500
            MGE Galaxy 4000
            MGE Galaxy 5000
            MGE Galaxy 5500
            MGE Galaxy 6000
            MGE Galaxy 7000
            MGE Galaxy 9000
            MGE Galaxy PW
            MGE Legacy
            MGE Service Bypass
            MGE Sinewave
            MGE Static Transfer Switches
            MGE UPS 4000
            Microsol Estabilizadores
            Microsol Modules Isoladores
            Mobile Notebook Stands
            Modular Components
            Modular Power Accessories
            Modular Power Distribution
            Monitor
            Mounting Hardware
            Mouse
            MRC1800
            MRE2400
            Multimedia
            MWF1700
            NetBotz 200
            NetBotz 300
            NetBotz 400
            NetBotz 500
            NetBotz Access Control
            NetBotz Accessories and Cables
            NetBotz Central
            NetBotz Rack Access
            NetBotz Sensors
            NetShelter CX
            NetShelter EP Enclosures
            NetShelter ES Enclosures
            NetShelter Open Frame Rack Accessories
            NetShelter SX
            NetShelter VL
            NetShelter VS Enclosures
            NetShelter VX Enclosures
            Network Integration Services
            Network Patch Cables
            NetworkAIR Accessories
            NetworkAIR AFX
            NetworkAIR CM
            NetworkAIR CW
            NetworkAIR FM
            NetworkAIR IR
            NetworkAIR TC
            Notebook Security
            On Site Service
            Open Frame Racks
            Operations Capacity
            Operations Change
            Operations Energy Cost
            Operations Energy Efficiency
            Operations Insight
            Operations Mobile
            Operations VIZOR
            Outdoor Enclosures
            Panelmount Environmental Monitoring
            Parallel
            Patch Panels
            PC1200
            Planning Tools and Publications
            Portable Cooling
            Power Cords
            Power Distribution Units
            Power Generation Systems
            Power Ready Notebook Cases
            PowerChute Business Edition
            PowerChute Inventory Manager
            PowerChute Network Shutdown
            PowerChute Personal Edition
            PowerChute plus
            PowerManager
            PowerShield
            Preventive Maintenance
            Project Management Services
            ProtectNet
            Rack Air Distribution
            Rack Components
            Rack LCD Consoles
            Rack PDU Accessories
            Rack-mount Transfer Switches
            Refrigerant Distribution
            Remote Monitoring Services
            Replacement Batteries
            Replacement Notebook Batteries
            Residential Hardwire Surge Suppression
            Retail
            Retractable Cables
            Room Air Distribution
            Room Cooling Accessories
            Router Cables
            Row Cooling Accessories
            SCSI
            Security Cameras
            Sensors
            Serial
            Service Bypass Panel
            Service Plans
            Silcon
            Silcon Accessories
            Silcon Battery Systems
            SLM/FLM Series
            SmartSlot Expansion Chassis
            Smart-UPS
            Smart-UPS Accessories
            Smart-UPS Battery Systems
            Smart-UPS DP
            Smart-UPS On-Line
            Smart-UPS RT
            Smart-UPS VT
            Software Configuration
            Software Education
            Software for NetBotz Appliances
            Software Installation
            Software Integration
            Spare Part Kits
            Specialty Enclosures
            Start-Up Service
            Stationary Power Distribution Units
            Step-Down Transformer
            StruxureWare Central
            StruxureWare Operations Suite
            SurgeArrest Essential
            SurgeArrest Home/Office
            SurgeArrest Notebook
            SurgeArrest Performance
            Switch Boxes
            Switched Rack PDU
            Symmetra
            Symmetra Accessories
            Symmetra Battery Systems
            Symmetra MW
            Symmetra MW Accessories
            Symmetra Power Module
            Symmetra PX
            Symmetra PX Accessories
            Sync and Charge Cables
            Thermal Containment
            Thick and Thin Ethernet
            Token Ring
            Toploading Cases
            Traditional Cases
            Training Services
            Transceivers
            Transportation
            Travel Mice
            TSP Accessories
            TSP Battery
            TSP/Generator
            TSP/Total System Power
            Tune-UPS for Symmetra
            Uniflair Chilled Water
            Universal Mobile Device Batteries
            Universal Notebook Batteries
            Universal Notebook Power Adapter
            Universal Power Accessories
            Universal Power Adapters
            UPS Network Hub Card
            UPS Network Management Cards
            USB Adapters & Converters
            USB Cables
            USB Charging Cables
            USB Hubs
            Wall-mount Transfer Switches
            Wheeled Cases
            Wireless
            Wizards and Configurators
            WS200

            MGE RASP; Panel wiring for APC Products with the AP9610 or AP9613 Relay cards

            Issue:
            MGE RASP; Panel wiring for APC Products with the AP9610 or AP9613 Relay cards

            Product line:
            MGE RASP Panel

            Environment:
            All models/ All serial numbers

            Cause:
            Instruction on MGE RASP (Remote Alarm Status Panel) Panel wiring for APC Products with the AP9610 or AP9613 Relay cards

            Resolution:
            MGE RASP Panel wiring for APC Products with the AP9610 or AP9613 Relay cards

            Refer to attached file for more details.




            Which SmartSlot accessories are supported by the Galaxy 3500 (G3500) UPS?



            Issue

            Which SmartSlot accessories are supported by the Galaxy 3500 (G3500) UPS?


            Product Line

            • Data Center and Facility 3 Phase UPS
              • MGE Galaxy 3500 models

            Environment

            • All serial numbers
            • All firmware versions unless otherwise noted

            Cause

            The list below details what accessories are supported by the Galaxy 3500 UPS (G3500) and what measures must be taken to utilize them.


            Resolution



            • Network Management Card 2 - AP9630/30CH, AP9631/31CH


            The APC Network Management Card 2 SKUs AP9630/30CH and AP9631/31CH can be utilized with the G3500 UPS. The Network Management Card must be loaded with the sumx firmware application 5.0.3 or higher. The AP9631 ships with the G3500 UPS.

            The AP9810 Relay I/O dongle can also used with the AP9631 Network Management Card 2 to have dry contact functionality - (2) inputs, (1) output per AP9810 with a maximum of (2) AP9810 that can be attached.


            • Building Management Card (BMS) - AP9622


            The AP9622 BMS card is supported in the G3500 UPS. It can utilize some of the 3-phase Symmetra bit register/modbus map, which can be found on the AP9622 product page, but other registers may not report properly if you are not in a 3:3 configuration.



            • Dry Contact I/O SmartSlot Card - AP9610 or AP9613


            The AP9610 or AP9613 is supported in the G3500 UPS. For AP9610 (or AP9613 utilizing dip switch configurations only) you must use Configuration 2, as mentioned in knowledge base FA156152.  Alternatively, Configuration 4 and the onboard configuration utility can be utilized on the AP9613.

            Unfortunately, if you use the included APC accessory terminal screw board with the AP9610, the front panel/UPS door will not close correctly. In order to avoid this issue, there are a few options you can look into.

            1.) Purchase a right angle DB25 Male-Female interconnection

            2.) Utilize an APC AP9600 single slot SmartSlot expansion chassis and extend the cable to the AP9600 with a 940-1500 serial cable. This communication cable can be routed so that the chassis can sit on top of the UPS. If using an AP9600, the NMC AP9630 or AP9631 should be in the AP9600 expansion chassis and the AP9610 should be in the SmartSlot in the UPS frame. This is the proper installation order per knowledge base article ID FA156034. (Note: This required installation order also applies to AP9613.)

            3.) Use an AP9604 SmartSlot triple chassis which comes with a 10' cable. This communication cable can be routed so that the chassis can sit on top of the UPS. Also, if do not want to use the included accessory board, you can make your own cable, using the pinout in the AP9610 user's guide and avoid buying a right angle 25 pin extension cable.

            4.) If using both an NMC and AP9610 or AP9613, put both the put the AP9610 or AP9613 and the NMC2 in the AP9604 triple chassis, referencing the correct installation order mentioned in knowledge base article ID FA156034 to ensure proper function of both the NMC2 and AP9610 or AP9613.


            • SmartSlot Serial Interface Expander - AP9607, AP9607CB, AP9624


            The SmartSlot serial interface expander can be used with the G3500 to supply two dedicated simple signaling ports, such as for use with an AS/400 or an IBM iSeries, if required.

            The Interface Expander 2 (AP9624) is also supposed by the G3500 and was released in mid-2014 to replace AP9607 and AP9607CB.






            Is the LP9618 key made of brass?

            Issue:
            Is the LP9618 key made of brass?

            Product Line:
            Panelboard

            Environment:
            Product features

            Cause:
            What material is LP9618 made of

            Resolution:
            The LP9618 or NSR251 key is made of steel, not brass.




            Why does PowerChute Network Shutdown not establish communications with Network Management Card when entering Radius user?

            Issue:
            PowerChute Network Shutdown will not establish communications with Network Management Card when Radius is enabled.

            Product Line/s:
            PowerChute Network Shutdown
            Network Management Cards (NMC) AP9617, AP9618, AP9619, AP9630, AP9631, AP9635CH, AP9635, AP9640, AP9641

            Environment:
            All support OS

            Cause:
            Radius authentication is not supported by PowerChute Network Shutdown

            Solution:
            For AP9630, AP9631, AP9635 that are running firmware 6.8 and above and all AP9640, AP9641 you should enter a PowerChute user that will only be used by PCNS and the NMC for communication. PCNS and the NMC will not utilize the Radius user. Go to Configuration - Shutdown and add the PowerChute user and authentication phrase.



            For AP9630, AP9631, AP9635 running firmware  6.0 to 6.7.x PCNS and the NMC will not utilize the Radius user. Log into the NMC and verify the default apc user is enabled or create a new device or administrator user the PCNS and the NMC will use for communication. Then go to Configuration - Shutdown and select the PowerChute user from the User name dropdown menu. The PowerChute User Name dropdown menu is populated with local users that have Administrative or Device user privileges.


            For AP9630, AP9631, AP9635 running firmware earlier than 6.0 and all AP9617, AP9618, AP9619 switch the Network Card from Radius to Local Authentication Only and the PowerChute user will be the NMC administrator.


            PowerChute Network Shutdown fails to Turn UPS off when the Network Management Card AP9617, AP9618, or AP9619 are configured for HTTPS.

            Issue:
            PowerChute Network Shutdown fails to Turn UPS off when the Network Management Card AP9617, AP9618, or AP9619 are configured for HTTPS.

            Product Line:
            PowerChute Network Shutdown versions 3.1, 4.X
            with Network Management Cards: AP9617, AP9618, AP9619

            Environment:
            Supported operating systems for the relevant PowerChute Network Shutdown versions in Product Line above.

            Cause:
            An SSL handshake error occurs when Java 7 and 8 is installed on the system and PowerChute attempts to communicate with an AP9617, AP9618, AP9619.

            Solution:
            To correct the issue change the communication protocol between the NMC and PowerChute to HTTP. There is no HTTPS solution with PowerChute Network Shutdown versions 3.1 and 4.x

            Show More
