PowerTag 1PN MAX 63A Eenergy Sensor

Back to PowerTag Energy Sensor Home Acti9 System PowerTag Energy Sensor

PowerTag 1PN MAX 63A Eenergy Sensor

PowerTag 1PN MAX 63A Eenergy Sensor

Item Number: A9MEM1560

Where To Buy

Product Dimensions

Width icon

Widthsensor element: 18 mm

Height icon

Heightsensor element: 20 mm

Depth icon

Depthsensor element: 44.5 mm

See full specifications

Datasheet

Download

Barcode

Qty UoM EAN Colour
-
-
-
See all

Specifications

Design

Sustainable offer status

Green Premium product

Range

PowerLogic

Product or component type

energy sensor

Market segment

  • buildings: breaker voltage monitoring
  • buildings: cost allocation
  • buildings: overload alarm

Product destination

switchboard

Physical

Mounting mode

by screws (terminals)

[Ue] rated operational voltage

200...240 V AC, +/- 20 %

Standards

  • IEC 61557-12
  • IEC 61010-1
  • IEC 61010-2-030
  • IEC 61326-1
  • ETSI EN 300 328
  • ETSI EN 301 487-1

Height

sensor element: 20 mm

Width

sensor element: 18 mm

Depth

sensor element: 44.5 mm

Net weight

16 g

Ambient air temperature for operation

-25...60 °C

Ambient air temperature for storage

-40...85 °C

IP degree of protection

IP20 conforming to IEC 60529

IK degree of protection

IK05

Relative humidity

0...95 % at 45 °C conforming to IEC 60721...3-3

Environmental characteristic

  • dustproof class 3S3 conforming to IEC 60721-3-3
  • salt mist class 3C2 conforming to IEC 60721-3-3
  • indoor use

REACh Regulation

Reference contains Substances of Very High Concern above the threshold

EU RoHS Directive

Compliant

Mercury free

Yes

RoHS exemption information

Yes

China RoHS Regulation

Product out of China RoHS scope. Substance declaration for your information

Environmental Disclosure

ENVPEP2007002

Circularity Profile

ENVEOLI2007002

California proposition 65

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Range compatibility

  • Acti 9 iCV40
  • Vigi iC40
  • Vigi iC60
  • Acti 9 iDD40 XA
  • Acti 9 iCV40 XA
  • Vigi iDT40

Mounting support

on circuit breaker

Others

Certification Number

DC-E-S26-061.6 - IRAM

Form factor

flex

Electrical connection

wires with cable end

Cable cross section

  • 1 rigid cable 1.5...16 mm²
  • 2 stranded cable 1.5...2.5 mm²
  • 2 rigid cable 1.5...2.5 mm²
  • 1 stranded cable 1.5...16 mm²

Cable length

0.25 m

Cable composition

1 x 0.33 mm²

Network frequency

  • 50 Hz
  • 60 Hz

Power consumption in VA

1 VA

Compatibility code

PowerTag A9 P63

Quality labels

CE

Directives

2014/53/EU - radio equipment directive

Operating altitude

0...2000 m

Overvoltage category

III conforming to IEC 61010-1

Measurement category

category III conforming to IEC 61010-2-030

Pollution degree

3

Vibration resistance

3M4 conforming to IEC 60721-3-3

Electromagnetic compatibility

  • industrial electromagnetic environment conforming to IEC 61326-1
  • radiated EMC conforming to ETSI EN 301 489-17
  • electromagnetic emission conforming to IEC 62311

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Weight

58.0 g

Package 1 Height

6.4 cm

Package 1 width

7.4 cm

Package 1 Length

8 cm

Unit Type of Package 2

S02

Number of Units in Package 2

30

Package 2 Weight

1.929 kg

Package 2 Height

15 cm

Package 2 width

30 cm

Package 2 Length

40 cm

WEEE

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

Product name

PowerTag A9 F63

Poles description

1P + N

Max current

63 A

[Ib] basic current

10 A

Starting current

40 mA

Saturation current

130 A

Product specific application

  • cost allocation
  • load monitoring
  • circuit monitoring
  • overload alarm
  • energy management

Concentrator compatibility

  • Acti9 Smartlink SI B
  • Acti9 Smartlink SI D
  • Acti9 PowerTag Link C
  • Acti9 PowerTag Link
  • Acti9 PowerTag Link HD
  • Harmony Hub
  • Wiser IP module
  • EcoStruxure Panel Server Universal
  • PrismaSet Active

Type of measurement

  • active energy
  • current
  • voltage
  • power factor
  • active power

Accuracy class

  • class 1 current conforming to IEC 61557-12
  • class 0.5 voltage conforming to IEC 61557-12
  • class 1 active power conforming to IEC 61557-12
  • class 1 active energy conforming to IEC 61557-12
  • class 1 power factor conforming to IEC 61557-12

Mounting location

top or bottom

Event management

voltage loss with measured current at voltage loss

Transmission support medium

radio frequency 2.4-2.4835 GHz conforming to IEEE 802.15.4

Emission power

10 mW
