Mini Duct, PVC, Standard Duct - 4 Metre Lengths, 40 x 25mm Rectangular WE, BR

White Electric | Mini Duct, PVC, Standard Duct - 4 Metre Lengths, 40 x 25mm Rectangular WE, BR

Mini Duct, PVC, Standard Duct - 4 Metre Lengths, 40 x 25mm Rectangular WE, BR

Item Number: 900/40/25-WE

Retail
$122.60
RRP (Inc. GST)

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Product brand

Clipsal

Range of product

Series 900

Sustainable offer status

Green Premium product

Physical

Height

40 mm

Width

25 mm

Length

4000 mm

Fixing mode

  • double-sided adhesive tape
  • by screws
    • REACh Regulation

      Free of Substances of Very High Concern above the threshold

      REACh free of SVHC

      Yes

      EU RoHS Directive

      Pro-active compliance (Product out of EU RoHS legal scope)

      Toxic heavy metal free

      Yes

      Mercury free

      Yes

      RoHS exemption information

      Yes

      China RoHS Regulation

       Pro-active China RoHS declaration (out of China RoHS legal scope)

      Environmental Disclosure

      ENVPEP100108EN

      Material

      Material

      PVC (polyvinyl chloride)

      Others

      Busbar cross section

      40 x 25 mm²

      Package 1 Weight

      1.094 kg
      Show all specifications

      Frequently Asked Questions

      hide show

      What is the end cap for the Clipsal 900/25/25

      No end cap fitting available for this size

      Does the 900/25/25 have pre-drilled holes?

      No, it does not have pre-drilled holes.
      For more information, please refer to the link:​https://www.clipsal.com/Trade/Products/ProductDetail?catno=900/25/25

      Is 900/50/50 PVC Maxi duct UV resistant?

      Unfortunately not, they are not UV resistant.

      For further information, please visit https://www.clipsal.com/Trade/Products/ProductDetail?catno=900/50/50

      Are the Clipsal 900/40/25T-WE Tees still available?

      No, the 900/40/25T-WE is a discontinued item

      Can I purchase end caps for the Clipsal 900/25/16 trunking

      Yes, the part number for end plugs is Clipsal 900/25/16P

      What replaces the line isolation and overload monitor E05/36/2 and E05/48/2?

      The part number for the line isolation and overload monitor is MLHG6. The MLHG6 line isolation and overload monitor replaces both E05/36/2 and E05/48/2.
      The MLHG6 requires a wall box, the part number for the wall box is MLHG6B-AU.
      Some of the key features are:
      • Programmable for current monitoring up to 100A
      • In-built test / verification module
      • Tracks data history of operational mode and faults
      • Fully approved to AS/NZS4510:1999 Isolated Electrical Supplies for Medical Uses
      • Meets requirements for AS/NZS3003:2011 Electrical Installations – Patient Areas of Hospitals
      • Potential to integrate into BMS
      For further information please visit https://www.clipsal.com/Trade/Products/ProductDetail?catno=MLHG6
