Socket Outlet Surface 3 PIN Flat 20A

Grey | Socket Outlet Surface 3 PIN Flat 20A

Socket Outlet Surface 3 PIN Flat 20A

Item Number: 56SO320FLE-GY

Retail
$214.14
RRP (Inc. GST)

Product Dimensions

Width icon

Width101 mm

Height icon

Height107 mm

Depth icon

Depth64 mm

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

Series 56

Range

Clipsal - 56 Series

Product brand

Clipsal

Product or component type

socket-outlet

Device application

power supply

Market segment

  • industry
  • utility
  • small commercial
    • Sustainable offer status

      Green Premium product

      Physical

      Outlet standard

      Australian/New Zealand

      Device mounting

      surface

      Mounting mode

      external mounting

      [In] rated current

      20 A

      [Ue] rated operational voltage

      250 V AC 50 Hz conforming to EN 60309-2

      Connections - terminals

      screw terminals 2.5-6 mm² rigid or stranded cable

      Socket number

      1

      Outlet standard

      industrial

      Net weight

      0.22 kg

      Depth

      64 mm

      Width

      101 mm

      Height

      107 mm

      Ambient air temperature for operation

      -25-75 °C

      Standards

      AS/NZS 3112

      REACh Regulation

      Reference contains Substances of Very High Concern above the threshold

      EU RoHS Directive

      Compliant

      Mercury free

      Yes

      RoHS exemption information

      Yes

      China RoHS Regulation

      Product out of China RoHS scope. Substance declaration for your information

      Environmental Disclosure

      ENVPEP120809EN

      Material

      Material

      polycarbonate: cover

      Contacts material

      screws: brass

      Others

      Number of Units in Package 1

      1

      Package 1 Height

      65 mm

      Package 1 Length

      100 mm

      Package 1 width

      100 mm

      Unit Type of Package 1

      PCE

      Plug, socket category

      low voltage

      Poles description

      1P + N + E

      Voltage colour

      blue

      Duration

      6 h

      Tightening torque

      0.8 N.m

      Socket-outlet type

      F

      Targeted country

      Australia

      Package 1 Weight

      226 g
      Show all specifications

      Documents & downloads

      hide show
      Filter items
      • All

      • Product Brochures

      • CAD Files and Packs

      • Technical Data Catalogues

      • Product Environmental

      • Specifications

      • Certificates (MSDS)

      • Corporate Marketing

      Frequently Asked Questions

      hide show

      What is a plug to suit part number 56SO532/6LE?

      Unfortunately, we do not have a plug to suit 56SO532/6LE.

      What is the 3 flat pin 20 amp socket in 56 series PDL56SO320

       It is a PDL 56SO320FLEGY

      Do you have a 56SO310 that is auto switched?

      Yes, we do  have a 56SO310 that is auto switched. The part number is 56SO310A.

      How do I get a 56 Series Double outlet?

      56E4 (4 Gang Base) + 56SO310LE (socket outlet) X2 + 56SW110LE (Switch) X2

      What is a 56 Series forward / reverse switch?

      A PDL 56SW320FR

      Is there a standard 20A socket available in the PDL 600 Series?

      No. The only 20A flat pin socket is in the PDL 56 Series - PDL 56SO320F
