Push Button Control Station, 3A, Latching

Grey | Push Button Control Station, 3A, Latching

Push Button Control Station, 3A, Latching

Item Number: 56PBS2-GY

Datasheet

Product Dimensions

Width icon

Width101 mm

Height icon

Height107 mm

Depth icon

Depth102 mm

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

Series 56

Range

Clipsal - 56 Series

Product brand

Clipsal

Product or component type

switch

Device application

control

Colour

cover: grey

Market segment

  • utility
  • industry
  • small commercial

Sustainable offer status

Green Premium product

Physical

[In] rated current

10 A

Control type

push-button

Connections - terminals

screw terminal cable(s) 1-4 mm² solid

Width

101 mm

Height

107 mm

Depth

102 mm

Net weight

0.36 kg

Marking

STOP

IP degree of protection

IP66

Ambient air temperature for operation

-25...75 °C

IP degree of protection

IP66 conforming to AS 60529

Standards

  • AS/NZS 3100
  • AS/NZS 3133

REACh Regulation

Reference contains Substances of Very High Concern above the threshold

EU RoHS Directive

Compliant

Mercury free

Yes

RoHS exemption information

Yes

China RoHS Regulation

Product out of China RoHS scope. Substance declaration for your information

Environmental Disclosure

ENVPEP120809EN

Others

Package 1 Bare Product Quantity

1

[Us] rated supply voltage

lamp: 500 V AC 50 Hz

Poles description

1P

Suitability for isolation

no

Tightening torque

0.8 N.m

Cap/operator or lens colour

red

Targeted country

Australia

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

10.4 cm

Package 1 Width

10.4 cm

Package 1 Length

10.6 cm

Package 1 Weight

358.0 g
