DESCRIPTION
|
APC PN#
|
QTY
|
Manufacturing #
|
|
***USC Special Orders
|
QAIRDIST-MISC
|
|
|
|
ASSY CORR BD TWF06 ROHS
|
0P9028A
|
1
|
|
|
BAYING BRACKET NETSHELTER SX
|
870-11538
|
2
|
|
|
BAYING BRACKET SCREW M5 X 12 FLT UCUT PHIL M5 X 12 BLK (for baying kit)
|
803-5006A
|
2
|
|
|
BOX ASSY for DUCT KIT ACSC 5KW
|
0M-61250
|
1
|
|
|
CABLE ASSY RELATIVE HUMIDITY SENSOR
|
W0N-0297[RH1] front
|
1
|
|
|
CABLE ASSY RELATIVE HUMIDITY SENSOR
|
W0N-0865[RH2] Rear
|
1
|
|
|
CABLE ASSY Temperature Humidity Sensor
|
AP9335TH
|
|
|
|
CABLE ASSY Temperature Sensor
|
AP9335T
|
|
|
|
CABLE ASSY TEMPERATURE SENSORS
|
0J-0W3163A {8FT}
|
|
|
|
CABLE ASSY TEMPERATURE SENSORS (Rack Inlet)
|
0J-0W2818A {13FT}
|
1
|
|
|
CAP MTL PPR 400V 5% 40UF RD (compressor)
|
W234-1406 (234-1406)
|
|
|
|
CAP MTL PPR 450V 55UF WITH TAP (compressor)
|
W234-0556 (234-0556)
|
|
|
|
CASTER STEEL 2" RIGID DARKSTAR (rear)
|
870-6620
|
2
|
|
|
CASTER SWIVEL 650 LBS 2.8IN OH (front)
|
870-71046
|
2
|
|
|
Ceiling Tile Adapter 24" - Spare Part
|
W870-80333
|
|
|
|
Ceiling Tile Adapter 600mm - Spare Part
|
W870-80336
|
|
|
|
COMP Assy, SC, ROTARY 208-230/1/60 (Toshiba conversion kit)
|
W0H-0170
|
|
|
|
COMP Assy, SC, ROTARY 220-240/1/50 (Toshiba conversion kit)
|
W0H-0171
|
|
|
|
COMP, ROTARY 208-230/1/60, SC, TOSHIBA - SPARE PART
|
W875-3825
|
1
|
|
|
COMP, ROTARY 220-240/1/50 SC, TOSHIBA - SPARE PART
|
W875-3826
|
1
|
|
|
Compressor Wiring Harness (FSB )
|
W0W3418
|
|
|
|
CONDENSATE PUMP DUAL ASSY W/HOSES (Dual Condensate Pump)
|
0N-0993SE
|
|
|
|
CONDENSATE PUMP FITTING BARBED (Y barb fittings) .13"X.13"X.13" (inlet)
|
875-4367 (for Dual Condensate Pump)
|
|
|
|
CONDENSATE PUMP FITTING BARBED (Y barb fittings) .19"X.19"X.19" (outlet)
|
875-4368 (for Dual Condensate Pump)
|
|
|
|
CONDENSATE PUMP TUBE PVC .125IN ID .250IN OD (18" long PVC TUBE for 875-4367)
|
875-0481 (for Dual Condensate Pump)
|
|
|
|
CONDENSATE PUMP TUBE PVC .188IN ID .313IN OD (18" long PVC TUBE for 875-4368)
|
875-0857B (for Dual Condensate Pump)
|
|
|
|
CONDENSATE PUMP TUBE PVC .625IN ID .750OD (2.3 FEET (700 MM) LONG)
|
875-0482 (for Dual Condensate Pump)
|
|
|
|
CONDENSATE PUMP WIRE ASSY CP JUMPER (for activation without the water sensor kit)
|
0W3133
|
|
|
|
CONDENSATE PUMP WITH Float - Spare Part (Dual voltage 120v/208v)
|
0J-0011
|
1
|
|
|
CONDENSER COIL ASSY SC5
|
0M-61169
|
1
|
|
|
Condenser Fan 200mm Mixed Flow (INDIVIDUAL FAN)
|
W490-0079
|
3
|
|
|
CONNECTOR SET 17KW IR SPARES for Jumper
|
W0H-0127
|
|
|
|
CONVERSION TO TOSHIBA COMP KIT , SC, 50HZ - SPARE PART
|
W0H-0171
|
|
|
|
DC RECTIFIER, 500 WATT, 54VDC, WIDE INPUT, FULL SIGNALS, BLACK
|
W1TWF0500H54B
|
2
|
|
|
DIVIDER-'A' DUCT KIT ACSC 5KW 48ECT BC NKRAFT
|
871-3527
|
3
|
|
|
DIVIDER-'B' DUCT KIT ACSC 5KW 48ECT BC NKRAFT
|
871-3528
|
2
|
|
|
Door Key - Spare Part
|
W870-8135
|
|
|
|
DRIVER BIT COMBO TORX T20/T30 (tool kit)
|
815-0001
|
1
|
|
|
DUCTING KIT 24 INCH IR5
|
0M-61152 (0M-61250)
|
1
|
|
|
ELECTRONIC EXPANSION VALVE Harness (HBGP harness )
|
0W4409
|
|
|
|
ELECTRONIC EXPANSION VALVE, 3/8" ODF (HGBP)
|
875-4275A
|
1
|
|
| |
|
|
|
|
EVAPORATOR FAN MODULE ASSY - 17 KW IR
|
W0M-61005
|
3
|
|
|
FAN 12VDC 60X25MM 25CFM ROHS (individual fan)
|
490-0030
|
1
|
|
|
FAN FUSE NTC COMPLETE 818 PCB CRAC
|
0P2390
|
3
|
|
|
FILTER - NON -WASHABLE PRINTING IR SERIES 2 IN THK
|
W0B1657
|
|
|
|
FILTER - WASHABLE IR SERIES 1/2" THK - SPARE PART
|
W875-2010
|
|
|
|
FITTING 1/8" BARB 10-32
|
870-80064
|
|
|
|
FITTING 1/8" BARB TEE (for air differential pressure switch)
|
870-80066
|
1
|
|
|
FLOAT SWITCH BULK MOUNT 4" MNL
|
0N-0279A
|
2
|
|
|
FLOAT SWITCH, BULKHEAD MOUNT (single float)
|
540-0205
|
1
|
|
|
FILTER-DRIER 3/8"ODF SOLDER
|
w875-2085
|
1
|
|
|
FM TOOL KIT SUB ASSY
|
0M-5383
|
|
|
|
FOOT LEVELING M10 X 51 L X 28 OD NYLOK
|
825-0035C
|
2
|
|
|
Front Door Assembly - Spare Part
|
W0M-61085
|
1
|
|
|
GROMMET RUBBER 1 1/2"ID X 1 3/4"GD X 1/8"GW (for power cable at the bottom)
|
827-0219
|
2
|
|
|
HI PRESS SW; OPENS 550PSIG CLOSES 400PSIG
|
w541-0087
|
1
|
20PS11-0003
|
|
InRow RC/SC Filter 1/2" Washable - Spare Part (default)
|
W875-2010
|
1
|
|
|
JUMPER PHASE SELECT
|
0W3268
|
|
|
|
LATCH FLUSH SLAM W/ TUMBLER #333 (for side door panels)
|
840-0192-333
|
2
|
|
|
Leak Sensor - 20 ft (6.1 m) (ships with orange sensor [AP9326] & black Cat5e cable)
|
AP9325
|
|
|
|
LOCTITE 554 - REFRIGERANT THREAD SEALING
|
690-0144
|
0
|
|
|
NMC with CAN controller (Embedded)
|
WAP9517CAN
|
32
|
|
|
PCB ASSY 5KDX BOARD SET (MB,WC,XA,DP)
|
W0P2476
|
1
|
|
|
PCB ASSY, Motherboard W/SIMM AND Mini-Rhodes
|
W0P2370
|
|
|
|
PCB CRAC 2X DP SIMM 805 COMPLETE (differential Pressure Switch)
|
W0P2354A
|
1
|
|
|
PCB CRAC MB COMPLETE 801 (motherboard)
|
W0P2340
|
1
|
|
|
PCB XA SIMM 879 Complete Assy - Spare Part (XA card)
|
W0P2342
|
|
|
|
PowerView - Spare Part
|
WAP9233
|
1
|
|
|
PRESSURE TRANSDUCER 2CP5
|
875-3400
|
2
|
|
|
PWR Backplane 802 PCB CRAC - Spare Part
|
W0P2341
|
1
|
|
|
PWR CORD IEC-C19 FEM TO L6-20P LCDI
|
960-0126
|
1
|
|
|
Pwr Cord, 16A, 200-240V, C19 to L6-20
|
AP9871
|
|
|
|
REAR DOOR ASSY - 17 KW
|
0M-61004B
|
1
|
|
|
Relay Coil 250V 25A DPNO 24DC [compressor relay]
|
W450-0024
|
|
|
|
RELAY DPDT 120VAC 8A PC MOUNT
|
450-0302
|
1
|
|
|
RELAY PWR SPDT 16A/250V 20A/125V NO 24V
|
450-0012A
|
1
|
|
|
SIDE PANEL ASSY - IR SERIES
|
W0M-61031
|
4
|
|
|
STRAIN RELIEF HEYCO SR 7N-2 (for control box)
|
652-07N2
|
3
|
|
|
TELECOUPLNG 8P8C RJ45 STRAIGHT
|
750-0034
|
1
|
|
|
TELECOUPLNG 8P8C RJ45 STRAIGHT (ethernet telecoupler)
|
W750-0034
|
|
|
|
TERMINATOR ROHS EXT BATT COMM BOARD (for communication board)
|
0W04161A
|
1
|
|
|
Thermistor/Probe EMU Cable ASSY - Spare Part (13FT PURPLE)
|
W0W2818 (0W2818)
|
1
|
|
|
TUBE 6 FT 10" DIA FLEX DUCT
|
875-0922A
|
3
|
|
|
TUBE PVC .125IN ID .250IN OD
|
875-0481
|
|
|
|
TUBE PVC .188IN ID .313IN OD
|
875-0857B
|
|
|
|
TUBING PVC CLEAR 0.25ID
|
660-7001D
|
|
|
|
TXV VALVE 3/8"ODM X 5/8" ODF R410A 1.5 TON
|
w875-1002
|
1
|
BBIZE-1.5-ZCP180BP5
|
|
Wire Assembly Base
|
W0W3287
|
|
|
|
WIRE ASSY SC5 COMPRESSOR (for FSB AT0093GB001)
|
W0W3418
|
1
|
|
|
WIRE ASSY SC5 LOWER PWR FEED MB
|
0W3288A
|
1
|
|
|
WIRE ASSY SC5 PRESSURE SENSING
|
0W3293B
|
1
|
|
|
WIRE ASSY SC5 PSU/CP PWR/48VDC OUT
|
0W3290A
|
1
|
|
|
WIRE ASSY SC5 UPPER PWR FEED MB
|
0W3291A
|
1
|
|
|
WIRE CLIP - BLACK AP9335TH (holds sensor cables)
|
870-13220
|
4
|
|
|
WIRE TIE 4X.1X.04 BLK
|
820-0247-010
|
2
|
|
|
XFMR ISOLATION1:1.3 MAX253
|
430-0244
|
1
|
|
|
1U Airflow Management Blanking Panel Kit (Qty 2) Black
|
AR8108BLK
|
|
|
|
1U 19" Black Modular Toolless Airflow Management Blanking Panel - Qty 10
|
AR8136BLK
|
|
|
|
1U 19" Black Modular Toolless Airflow Management Blanking Panel - Qty 200
|
AR8136BLK200
|
|
|
|
|
|
|
|
