Max 4 Miniature Circuit Breakers, 1 Pole, 1 Module, 18mm, 240V, 32A, 10kA

Max 4 Miniature Circuit Breakers, 1 Pole, 1 Module, 18mm, 240V, 32A, 10kA

Max 4 Miniature Circuit Breakers, 1 Pole, 1 Module, 18mm, 240V, 32A, 10kA

Item Number: 4CB132/10

Retail
N/A
RRP (Inc. GST)

Product Dimensions

Width icon

Width18 mm

Height icon

Height81 mm

Depth icon

Depth78.5 mm

See full specifications

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Product brand

Clipsal

Sustainable offer status

Green Premium product

Physical

Number of poles

1

[In] rated current

32 A

[Ue] rated operational voltage

240 V

Mechanical durability

20000 cycles

Electrical durability

10000 cycles

Connections - terminals

  • screw terminal for 1 cable(s) 0.5-35 mm² rigid
  • screw terminal for 1 cable(s) 0.5-25 mm² flexible
  • screw terminal for 1 cable(s) 0.5-25 mm² flexible with ferrule
    • Wire stripping length

      13 mm

      IP degree of protection

    • IP20 conforming to IEC 60529
    • IP40 (modular enclosure) conforming to IEC 60529
      • Ambient air temperature for operation

        -25-70 °C

        Ambient air temperature for storage

        -40-70 °C

        Standards

        AS/NZS 60898

        Relative humidity

        95-95 % at 55-55 °C

        Height

        81 mm

        Width

        18 mm

        Depth

        78.5 mm

        Net weight

        115 g

        EU RoHS Directive

        Compliant

        Mercury free

        Yes

        RoHS exemption information

        Yes

        China RoHS Regulation

        Product out of China RoHS scope. Substance declaration for your information

        Environmental Disclosure

        ENVPEP1304004

        Others

        Curve code

        C

        Number of modules

        1

        Breaking capacity

        10 kA conforming to EN 60898

        Network type

        AC

        Network frequency

        50/60 Hz

        [Ui] rated insulation voltage

        500 V

        Tightening torque

        3.5 N.m

        Tropicalisation

        2

        Package 1 Weight

        118 g

        Package 1 Height

        72 mm

        Package 1 width

        85 mm

        Package 1 Length

        18 mm
        Show all specifications

        Frequently Asked Questions

        hide show

        What is the cable size to suit 4CB3100/10?

        The part number 4CB3100/10 will accommodate up to 50mm2 normal cable and up to 35mm2 flexible cable.

        What is the part number for a 3 pole 32amp D-Curve C/B

        The part number for a 3 pole 32amp D-Curve C/B is a 4CB332D10.

        For further information please visit https://www.clipsal.com/Trade/search-results?q=4CB332D10

        User-added image

        What size cables fit into the 4CB3125/10?

        If the cable is Rigid/ Semi Rigid the 4CB3125/10 breaker will take a cable from 1mm²- 50mm².

        OR

        If the cable is Flexible or Ferrule the 4CB3125/10 breaker will take a cable from 1.5mm²- 35mm².

        Is there a lock-off to suit the 4CB3100/10?

        Yes, the Schneider MGN26380 will suit the Clipsal Max 4 Range.

        What is the part code for a 56 Series with a 32a 10ma RCBO

        Part codes you need a PDL 56CB4  with a 4RCBE232/10

        Do 4CB series circuit breakers have different color toggles?

        No,previous models had different color toggles for different current ratings but unfortunately current models do not.
        For further information please visit the following link:
        https://www.clipsal.com/trade/search-results?q=circuit
