Insulating Back Plate

Black | Insulating Back Plate

Insulating Back Plate

Item Number: 449AP-BK

Retail
N/A
RRP (Inc. GST)
Colour Black (BK)
  • Black 1 PCE

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Product brand

Clipsal

Product or component type

insulating plate

Physical

Depth

10 mm

Length

126 mm

Width

84 mm

REACh free of SVHC

Yes

EU RoHS Directive

Pro-active compliance (Product out of EU RoHS legal scope)

Toxic heavy metal free

Yes

Mercury free

Yes

RoHS exemption information

Yes

China RoHS Regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Material

Material

PVC (polyvinyl chloride)

Others

Shape

rectangular

Mounting location

back side

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Weight

0.061 kg

Package 1 Height

10 mm

Package 1 width

84 mm

Package 1 Length

126 mm
Show all specifications

Documents & downloads

hide show
Filter items
  • All

  • Product Brochures

  • Technical Data Catalogues

Frequently Asked Questions

hide show

What is the part number for an insulating back plate for a 449A?

The part number for an insulating back plate for a 449A is 449AP.

Some of the key features are:
  • Provides 10 mm extra depth for additional cabling
  • 4 mounting screw positions
  • Mounting direction: Horizontal and vertical

For further information please visit https://www.clipsal.com/Trade/Products/ProductDetail?catno=449AP





what is the part no for a shallow mounting block like the 449A?

the part no is 449ASD
https://www.clipsal.com/Trade/Products/ProductDetail?catno=449ASDUser-added image

Do the 448 and 449A, both suit the Prestige range?

Yes, they do suit the Prestige Range.

For more information, please refer to the link:
https://www.clipsal.com/Trade/Products/ProductDetail?catno=448
https://www.clipsal.com/Trade/Products/ProductDetail?catno=449A





What is mounting block to suit P2031VH?

Part no P2031VH will fit on either 449A or 449ASD mounting block

What is the mounting block to suit the PDL 800 Series

The 449C is deep (34mm) and the 449CSD is shallow (16mm).
Both can be fitted to the 449BAP to create a double insulated mounting block, this will add 9mm to the depth..

Is the 449A available in transparent?

Yes, the 449A is available in transparent. The part number is 449A-TR.

Some of the key features are:
  • Moulded surface mounting blocks
  • With metal inserts
  • 6 mounting screw positions
  • Mounting direction:Horizontal and vertical
  • 12 combined cable/conduit cut-outs
For further information please visit https://www.clipsal.com/Trade/Products/ProductDetail?catno=449A
