Solid Fittings - PVC, Conduit Caps, 16mm

Grey | Solid Fittings - PVC, Conduit Caps, 16mm

Solid Fittings - PVC, Conduit Caps, 16mm

Item Number: 262/16-GY

Retail
$1.97
RRP (Inc. GST)

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Product brand

Clipsal

Range of product

Series 262

Sustainable offer status

Green Premium product

Physical

Length

20 mm

REACh Regulation

Free of Substances of Very High Concern above the threshold

REACh free of SVHC

Yes

EU RoHS Directive

Pro-active compliance (Product out of EU RoHS legal scope)

Toxic heavy metal free

Yes

Mercury free

Yes

RoHS exemption information

Yes

China RoHS Regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Environmental Disclosure

ENVPEP100802EN

Material

Material

PVC (polyvinyl chloride)

Others

Diameter

  • inner: 16 mm
  • outside: 20 mm
    • Unit Type of Package 1

      PCE

      Number of Units in Package 1

      1

      Package 1 Weight

      3 g

      Package 1 Height

      20 mm

      Package 1 width

      20 mm

      Package 1 Length

      20 mm
      Show all specifications

      Frequently Asked Questions

      hide show

      Are the Clipsal Conduit Clips available in Electric Orange?

      No, they are only available in grey.

      This applies to the 280/16 (16mm), 280/20 (20mm), 280/25 (25mm), 280/32 (32mm), 280/40 (40mm) and 280/50 (50mm).

      What is the standard pack size of the 262/25?

      The standard pack size of the 262/25 is 50

      Some of the key features are:
      • Rigid Tube
      For further information please visit https://www.clipsal.com/Trade/Products/ProductDetail?catno=262/25


      What screws would suit a 265/1-GY.

      The part number for the screws would be 265SCREW.

      Is the junction box 265/1 UV rated?

      No it doesn't have a rating as such, however it is UV resistant.

      What are the dimensions for a 261S Saddle Spacer?

      The dimensions for a 261S Saddle Spacer are 261S are:

      Saddle Spacers
      Catalogue NumberSizeLength (L)Width (W)Centres (CRS.)Standoff (T)Height (H)
      261S1616mm55mm21mm32mm8mm14mm
      261S2020mm61mm22mm40mm8mm14mm
      261S2525mm74mm26mm48mm8mm14mm

      Saddles Spacers set a conduit run off the wall 8mm to allow easier cleaning and repainting and to facilitate entry into equipment. They are available in sizes 16mm through 25mm.
      Standard colour is Grey (GY), with Orange (EO) also available at extra cost.

      For further information please visit www.clipsal.com/Trade/search-results?q=261S
