Twin Switch Socket Outlet, 250V, 10/15A, Skirt Mount for Ducting, Straight Side

Back to Single Switched Socket Home Switched Horizontal Single Switched Socket

White Electric | Twin Switch Socket Outlet, 250V, 10/15A, Skirt Mount for Ducting, Straight Side

Twin Switch Socket Outlet, 250V, 10/15A, Skirt Mount for Ducting, Straight Side

Item Number: 16/2MF1510-WE

Retail
$150.81
RRP (Inc. GST)
Colour White Electric (WE)
  • White Electric 1 PCE
  • Black 1 PCE
Where To Buy

Datasheet

Download

Barcode

Qty UoM EAN Colour
-
-
-
See all

Specifications

Design

Product brand

Clipsal

Range of product

Standard Series

Surface finish

glossy

Sustainable offer status

Green Premium product

Physical

Control type

ON/OFF button

Number of gangs

2 gangs

Pin number

3

Number of power socket outlets

2

Actuator

  • switch
  • rocker

      • Mounting position

      horizontal

      Fixing mode

      by screws

      Local signalling

      without light indicator

      [Ue] rated operational voltage

      250 V AC

      [In] rated current

    • 15 A
    • 10 A

        • Depth

        18 mm

        Length

        156 mm

        Width

        44 mm

        Fixing center

        136 mm

        Standards

      • AS/NZS 3100
      • AS/NZS 3112
      • AS/NZS 3133:approval number S/1

          • REACh Regulation

          Free of Substances of Very High Concern above the threshold

          EU RoHS Directive

          Compliant

          Mercury free

          Yes

          RoHS exemption information

          Yes

          China RoHS Regulation

          Product out of China RoHS scope. Substance declaration for your information

          Environmental Disclosure

          ENVPEP120506EN

          Material

          Material

          plastic

          Others

          Distance between centers

          145 mm

          Unit Type of Package 1

          PCE

          Number of Units in Package 1

          1

          Package 1 Weight

          116 g

          Package 1 Height

          35 mm

          Package 1 width

          45 mm

          Package 1 Length

          155 mm

          Unit Type of Package 2

          BB1

          Number of Units in Package 2

          5

          Package 2 Weight

          0.63 kg

          Package 2 Height

          74 mm

          Package 2 width

          120 mm

          Package 2 Length

          165 mm

          Unit Type of Package 3

          CAR

          Number of Units in Package 3

          50

          Package 3 Weight

          7 kg

          Package 3 Height

          226 mm

          Package 3 width

          191 mm

          Package 3 Length

          359 mm
          Show all specifications

          Documents & downloads

          hide show
          Filter items

          • All

          • Product Brochures

          • Technical Data Catalogues

          • Specifications

          31LCDA Load Correction Device - Enhanced Dimming Control for LED and CFL Lighting, 26847

          31LCDA Load Correction Device - Enhanced Dimming Control for LED and CFL Lighting, 26847

          199.8 KB PDF

          414 Twin Surface Sockets, 13522

          414 Twin Surface Sockets, 13522

          247.6 KB PDF

          A block for every job. Slimline, Modena and Strato Mounting Blocks, Surface Enclosures and Flanges, 26456

          A block for every job. Slimline, Modena and Strato Mounting Blocks, Surface Enclosures and Flanges, 26456

          231.1 KB PDF

          Australia's finest selection of quality Power Points & Switches - 11743

          Australia's finest selection of quality Power Points & Switches - 11743

          1.5 MB PDF

          Brochure for Medium Power Universal Dimmer 800W. Robust design

          Brochure for Medium Power Universal Dimmer 800W. Robust design

          1.2 MB PDF

          Choosing the correct surge protection equipment. An easy to use guide for contractors

          Choosing the correct surge protection equipment. An easy to use guide for contractors

          513 KB PDF

          Cooker switches that rock! 32/45A current carrying capacity, 116469

          Cooker switches that rock! 32/45A current carrying capacity, 116469

          838.3 KB PDF

          Electrical Essentials, Great Electrical ideas for anyone Building or Renovating

          Electrical Essentials, Great Electrical ideas for anyone Building or Renovating

          5 MB PDF

          Energy Efficiency Trade Product Guide, 20742

          Energy Efficiency Trade Product Guide, 20742

          1.7 MB PDF

          Insulated Safety Pin Products, Our plug for safety

          Insulated Safety Pin Products, Our plug for safety

          585.7 KB PDF

          Introducing Extrolex, A Clipsal Electrical Accessories and Olex initiative

          Introducing Extrolex, A Clipsal Electrical Accessories and Olex initiative

          455.8 KB PDF

          Power Solutions to get away - 12926

          Power Solutions to get away - 12926

          726.5 KB PDF

          Quick Connect, Very Quick Very Reliable

          Quick Connect, Very Quick Very Reliable

          3.1 MB PDF

          Residential Energy Efficiency Guide, 20097

          Residential Energy Efficiency Guide, 20097

          5.8 MB PDF

          Standard range weatherproof switchplate, the unique switchplate that has outdoor locations covered

          Standard range weatherproof switchplate, the unique switchplate that has outdoor locations covered

          464 KB PDF

          Stop your cooking equipment being beaten, battered and poached

          Stop your cooking equipment being beaten, battered and poached

          2 MB PDF

          Surge Protection Product Guide

          Surge Protection Product Guide

          100.6 KB PDF

          The new range of push-button timer switches

          The new range of push-button timer switches

          203.3 KB PDF

          Unlock the finest Metal Plate Range in the world - 9317

          Unlock the finest Metal Plate Range in the world - 9317

          2.9 MB PDF

          We've Nailed It. New, Improved 413NP Nail Plate. Its clearly easier and roomier

          We've Nailed It. New, Improved 413NP Nail Plate. Its clearly easier and roomier

          551.6 KB PDF

          Standard Series Technical Catalogue, No other range is up to standard

          Standard Series Technical Catalogue, No other range is up to standard

          5.3 MB PDF

          Technical Specifications - Socket Outlets - Standard Range

          Technical Specifications - Socket Outlets - Standard Range

          159.1 KB PDF

          Technical Specifications - Switches - Standard Range

          Technical Specifications - Switches - Standard Range

          188.6 KB PDF

          Frequently Asked Questions

          hide show

          Is there a skirting mount double power outlet rated to 15A, 250V?

          Unfortunately not, we do not have skirting mount double power outlet rated to 250V 15A .

          In 15A , 250V, skirting mount, we have the following options:

          16/15 -  Single Power Outlet 250V 15A, Skirting Mount, Plate size 98 x 41mm at centre.
          For further information, please visit
          https://www.clipsal.com/Trade/Products/ProductDetail?catno=16/15

          16/2MF1510 - Double Power Outlet 250V 15A and 10A combination, Skirting Mount, suits ducting (156.5 x 44mm).
          For further information, please visit
          https://www.clipsal.com/Trade/Products/ProductDetail?catno=16/2MF1510



          Is the PDL 598FWH available in double pole version

          No, you can use the Clipsal 16/2MFD-WE

          What is the part number for a skirting double GPO , with a 10amp & a 15amp outlet?

          The part number for a skirting double GPO , with a 10amp & a 15amp outlet is - 16/2MF1510

          For further information , visit link below:-
          https://www.clipsal.com/Trade/search-results?q=16/2MF1510
          User-added image

          What is the part no for skirting double gpo with 15A and 10A on the same product ?

          The part number is 16/2MF1510

          Please click this link for further information https://www.clipsal.com/Trade/Products/ProductDetail?catno=16/2MF1510

          User-added image
