Switched Socket Mechanism Double Pole 10A LT

White Electric | Switched Socket Mechanism Double Pole 10A LT

Switched Socket Mechanism Double Pole 10A LT

Item Number: 10MDL-WE

Retail
N/A
RRP (Inc. GST)
Colour White Electric (WE)
  • White Electric 1 PCE

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

Standard Series

Product brand

Clipsal

Sustainable offer status

Green Premium product

Physical

Outlet standard description

pin earth

Quantity per set

set of 1

Marking

without marking

Local signalling

without light indicator

Device mounting

flush

Fixing mode

by screws

[In] rated current

10 A

[Ue] rated operational voltage

250 V AC

Depth

25 mm

Length

94 mm

Width

42 mm

Fixing center

84 mm

Number of poles

2

Standards

  • AS/NZS 3100
  • AS/NZS 3112
  • AS/NZS 3133:approval number S/1
    • REACh Regulation

      Free of Substances of Very High Concern above the threshold

      REACh free of SVHC

      Yes

      EU RoHS Directive

      Compliant

      Toxic heavy metal free

      Yes

      Mercury free

      Yes

      RoHS exemption information

      Yes

      China RoHS Regulation

       Pro-active China RoHS declaration (out of China RoHS legal scope)

      Environmental Disclosure

      ENVPEP111024EN

      Circularity Profile

      ENVEOLI110713EN

      Others

      Cover type

      complete housing
      Show all specifications

      Documents & downloads

      hide show
      Filter items
      • All

      • Product Brochures

      • Technical Data Catalogues

      • Specifications

      • Certificates (MSDS)

      Frequently Asked Questions

      hide show

      Do Modena switches come with out LED

      All come with LED , ( Except the 80MH) but you do not need to connect the LED  if you do not want the LED indicator.

      For more information on this product range please visit the Clipsal web site on the supplied link https://www.clipsal.com/Trade/search-results?q=80m

      What is the part number of the replacement sockets for CFFB?

      10MDP is the part number of the replacement socket to suit CFFP.


      What is the part code for a RCBO 32amp 10m/a

       The part code is 4RCBE232/10

      What size cable will the T100-BK terminals accomodate?

      10mm2 to 50mm2

      Is there a 2 Pole, 10A, 10mA, RCBE?

      Yes, the part number for a 2 Pole, 10A, 10mA, RCBE is a 4RCBE210/01.
