Clipsal - Max 4 Residual current circuit breaker 2P 25 A 30 mA type AC 240V

Item Number: 4RC225/30

1 PCE 0

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	9318795006635	-
60	CAR	29318795006745	-

Specifications

Design

Range	MAX4
Product or component type	residual current circuit breaker (RCCB)
Product brand	Clipsal

Physical

[in] rated current	25 A
[ue] rated operational voltage	240 V AC
Mounting support	DIN rail
Standards	AS/NZS 61008
Ip degree of protection	IP40
Ambient air temperature for operation	-5...40 °C
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP2301023EN
Eu rohs directive	Compliant By Exemption

Others

Legacy weee scope	In
Package 1 bare product quantity	1
Average percentage of bio-based plastic content	0 %
Average percentage of recycled plastic content	0 %
	Outside of Europe
Warranty duration(in months) bmecat	18
Weee label	N/A
Poles description	2P
Number of modules	2
Earth-leakage sensitivity	30 mA
Earth-leakage protection class	type AC
Rated conditional short-circuit current	10 kA
[uimp] rated impulse withstand voltage	6 kV
Size	81 x 72 x 75 mm conforming to DIN 43880
Pollution degree	2
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	8 cm
Package 1 width	4 cm
Package 1 length	9 cm
Package 1 weight	209 g
Total lifecycle carbon footprint	39 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	3.666578643093759
Carbon footprint of the manufacturing phase [a1 to a3]	4 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.0503389241665822
Carbon footprint of the distribution phase [a4]	0.1 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.02254995359364957
Carbon footprint of the installation phase [a5]	0 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	34.46814814814813
Carbon footprint of the use phase [b2, b3, b4, b6]	34 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	0.9393751753091674
Carbon footprint of the end-of-life phase [c1 to c4]	0.9 kg CO2 eq.
Energy efficiency optimized	False
F-gas free	N/A
Total lifecycle carbon footprint	39.14699084431129
Average percentage of recycled metal content	0 %
Scip number	2c7837a4-39fc-4abc-96ed-2ef14f8f87c7
End of life manual availability	N/A
Warranty (in months)	18
