Datasheet
Specifications
Design
| Range | MAX4 |
|---|---|
| Product or component type | residual current breaker with overcurrent protection (RCBO) |
| Product brand | Clipsal |
Physical
| [in] rated current | 20 A |
|---|---|
| [ue] rated operational voltage | 240 V AC |
| Mounting support | DIN rail |
| Standards | AS/NZS 61009 |
| Ip degree of protection |
|
| Ambient air temperature for operation | -5...40 °C |
| Mercury free | Yes |
| Rohs exemption information | Yes |
| Environmental disclosure | ENVPEP2209021EN |
| Eu rohs directive | Compliant By Exemption |
