Specifications
Design
Product brand
Clipsal
Range of product
Series 247
Surface treatment
galvanised
Sustainable offer status
Green Premium product
Physical
Connector type
thread connector
Length
182 mm
Standards
AS 2052|AS 1721
Reach free of svhc
Yes
Eu rohs directive
Pro-active compliance (Product out of EU RoHS legal scope)
Toxic heavy metal free
Yes
Mercury free
Yes
Rohs exemption information
Yes
China rohs regulation
Pro-active China RoHS declaration (out of China RoHS legal scope)
Environmental disclosure
ENVPEP110719EN
Circularity profile
N/A
Material
Material
cast iron
Others
Package 1 bare product quantity
1
Diameter
40 mm
Operating angle
90 °
Inner radius
105 mm
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
4.7 cm
Package 1 width
4.7 cm
Package 1 length
25.5 cm
Package 1 weight
1031 g
